The navvy barrow usually employed in excavating operations, and for the transference of bricks, concrete, etc., is constructed of hard wood with wrought and cast-iron fittings and steel axles. The angles are bound with iron. The bottom should have a steel plate. The wheels may be of iron, or of wood bound with iron. A strong barrow varies in weight from 60 to 75 lbs., and has a capacity of about 1/10 of a cubic yard.

A barrow of this kind can be slung by passing a hook through the wheel and rings round the handles.

Handbarrows (Fig. 204) are used for carrying light loads and materials which cannot be rolled. These may also be slung.

Barrows 235

Fig. 205.
